Descrizione
129 dB Max SPL
1400 WATT 2-way peak power
Innovative DSP Processing
1″ Compression Driver, 1.75″ v.c.
10″ Woofer
90°x70°, wide dispersion constant directivity horn
FiRPHASE Technology
Acoustical specifications
FREQUENCY RESPONSE: 50 Hz ÷ 20000 Hz
MAX SPL @ 1M: 129 dB
HORIZONTAL COVERAGE ANGLE: 90°
VERTICAL COVERAGE ANGLE: 70°
Transducers
COMPRESSION DRIVER: 1.0”, 1.75” v.c
WOOFER: 10”, 2.5” v.c
Input/Output section
INPUT SIGNAL: bal/unbal
INPUT CONNECTORS: XRL, Jack
OUTPUT CONNECTORS: XLR
INPUT SENSITIVITY: -2 dBu/+4 dBu
MIC. INPUT SENSITIVITY: -32 dBu
Processor section
CROSSOVER FREQUENCIES: 1600 Hz
PROTECTIONS: Thermal, RMS
LIMITER: Soft Limiter
CONTROLS: Volume, Boost, Mic/Line
Power section
TOTAL POWER: 1400 W Peak, 700 W RMS
HIGH FREQUENCIES: 400 W Peak, 200 W RMS
LOW FREQUENCIES: 1000 W Peak, 500 W RMS
COOLING: Convection
CONNECTIONS: VDE
Standard compliance
CE MARKING: Yes
Physical specifications
CABINET/CASE MATERIAL: PP Composite
HARDWARE: 2 x M10
HANDLES: 1 Top
POLE MOUNT/CAP: Yes
GRILLE: Steel
COLOR: Black
Size
HEIGHT: 548 mm / 21.57 inches
WIDTH: 340 mm / 13.39 inches
DEPTH: 305 mm / 12.01 inches
WEIGHT: 14.2 kg / 31.31 lbs
